Laser Rangefinder Module

ES-LRFM-500

The ES Systems Laser Rangefinder Module is a state-of-the-art device designed for precise distance measurements to non-cooperative targets up to 4 kilometers. With an invisible 1550 nm wavelength, it ensures high performance without being detected by I²-based night vision. This compact and durable module, weighing only 39 grams, is ideal for integration into portable systems and handheld observation devices, making it a leading choice for tactical operations and weapon-mounted systems.
Description
Specifications
Applications
Similar Products
Description

The ES-LRFM-500 combines superior accuracy and rugged design, making it suitable for military, defense, and industrial applications. It can withstand shocks up to 1500g and offers a wide operating temperature range of -40°C to +65°C. The module's small size and lightweight make it one of the most portable and efficient devices in its class, while its fast response time ensures swift measurements in demanding environments.

Specifications
Wavelength (20 °C)
1550 nm
Laser Classification
Class 1
Operation Modes
Single Measurement, 1...10 Hz
Divergence
≤ 0.5 mrad
Measurement Range
10m...5000m
Accuracy
< 1m
Resolution
< 3m
Target Range Performance
Small Target
3000m (0.75 x 0.75m, Albedo 30%, 25Km Visibility)
NATO Standard Target
4000m (2.3 x 2.3m, Albedo 30%, 25Km Visibility)
Mechanical Shock
1500g, 1mSec
Dimensions
50 x 30 x 22 mm
Weight
≤ 39g
Name
Type
File
Flyer ES-LRFM-500
Flyer
844.88 K
Applications
Military and Defense

Weapon-mounted systems for precision targeting and surveillance.

Tactical Operations

Remote measurement for field operations, enhancing situational awareness.

Industrial Measurement

Measuring large distances in construction, mining, and infrastructure projects.
