ESPP-MIT1 Transmitter

The ESPP-MIT1 Transmitter by ES Systems is a highly accurate and cost-effective strain gauge pressure transmitter, designed for use in harsh industrial and HVAC environments. Built with a fully sealed stainless-steel construction, the transmitter provides reliable gas or fluid pressure measurements and is ready for immediate installation with factory-calibrated and temperature-compensated output.
Description
Specifications
Technical Information
Applications
Similar Products
Description

The ESPP-MIT1 Transmitter by ES Systems is a highly accurate and cost-effective strain gauge pressure transmitter, designed for use in harsh industrial and HVAC environments. Built with a fully sealed stainless-steel construction, the transmitter provides reliable gas or fluid pressure measurements and is ready for immediate installation with factory-calibrated and temperature-compensated output.

Key Features

The ESPP-MIT1 features a compact, micro-fused design with an all-welded, hermetically sealed stainless-steel structure, offering durability and resistance in challenging environments. Its output is pre-calibrated and temperature-compensated, ensuring minimal error and long-term reliability. The transmitter supports various electrical and process interfaces, making it a versatile and cost-effective solution for high-volume applications.

Specifications
Key Attributes
Pressure Type
Gauge
Pressure Range
Up to 1000bar
Power Supply
+8V … +28V
Total Error
< ±1.0%FS
Operating Temperature
-40oC …+125oC
Compensation Temperature
-10oC …+80oC
Output
Calibrated Pressure
Output Interface
4-20mA, 0.5V-4.5V, 1-5V, 0-5V
Overpressure Tolerance
Up to 5x
Media Compatibility
Gases, Liquids
Material
Stainless Steel 17-4PH
Connection Type
M12, ISO4400, Cable, Packard
Process Interface
G1/2″, G1/4″, 1/2″NPT, 1/4″NPT, …
Dimensions
Height: 66.5mm | diameter Ø23.5mm
Technical Information
Name
Type
File
Flyer ESPP-MIT1
Flyer
814.67 K
Datasheet ESPP-MIT1
Datasheet
496.64 K
Step Files ESPP-MIT1
Step Files
291.07 K
Applications
Central Air Conditioning Control Systems

The ESPP-MIT1 Transmitter provides accurate pressure monitoring in central AC systems, ensuring optimal operation and energy efficiency. It helps prevent damage to critical components like compressors and pumps by maintaining consistent pressure levels.

Energy & Water Treatment Systems

The ESPP-MIT1 Transmitter ensures consistent pressure in energy and water treatment systems, optimizing pump and filtration performance. It helps maintain system efficiency while preventing over-pressurization and ensuring safe operation.

Hydraulic & Pneumatic Systems

In hydraulic and pneumatic systems, the ESPP-MIT1 Transmitter ensures safe operation by monitoring pressure levels in key components. It detects pressure anomalies, improving system reliability and performance in industries such as manufacturing and transportation.
