Description
ES Systems has developed an environmental sensing board system featuring multiple sensors for environmental monitoring that can be utilized in a variety of applications and industries. The ESEN-MESN system integrates pressure, humidity, temperature, TVOC, CO, NO2, CO2 sensors that can be integrated in custom-tailored boards that fit each end user’s tailored defined mechanical specifications. ESEN-MESN supports both wired and wireless communication enabling optimal connectivity capabilities. The wireless capability enables installation in remote locations with minimal installation cost. ESEN-MESN supports various wireless communication protocols making it easy to integrate into any network infrastructure.
Specifications
General
Supply Voltage
3.3V, 24V
Communication Interface
I2C, RS-485 (MODBUS-RTU), WiFi, BLE
Pressure
Range
0-4barg
Total Error
± 1%FS
Compensating Temperature
0C … +60C
Humidity
Range
0-100% RH
Accuracy
± 2% RH
Temperature
Range
-40C … +125C
Accuracy
±0.2C
VOC
Range
0 … 60000ppb
Sensitive to
Acetone, Butylacetate, Cyclohexan, Ethanol, Formaldehyde, Hydrogen, Toluene
CO
Range
0 … 1000ppm
No2
Range
0.05 … 10ppm
CO2
Range
0 … 2000ppm
Resolution
1ppm
Accuracy
±50ppm +3%m.v.
